1. Application Scope:
This machine is suitable for vacuum or nitrogen-filled sealing packaging of electronic components, chemicals, food raw materials, fabrics and wool products, beans, dried goods, fresh fruits and vegetables, etc. It can achieve preservation and quality maintenance effects such as anti-oxidation, anti-corrosion, anti-mildew, and moisture protection.
This external vacuum packaging machine is suitable for single-seal or vacuum packaging. It can also be used for inert gas filling. If the packaged material is powder, a dust filter (optional) will be provided based on the powder particle size.
The sealing is typically single-sided heating, but double-sided heating (optional) is available to suit different bag thicknesses.
The machine is equipped with a liftable, non-powered conveyor platform with an adjustable range of 0-900mm to meet packaging requirements.
It is easy to operate. The standard sealing length is 600mm/700mm/800mm, but can be extended to 600mm to 1200mm upon request.
2. Technical parameter:
| Model |
DZQ—600 F |
| Effective sealing size(mm) |
600*8 |
| Voltage (V) Frequency (Hz) |
220V/ 50HZ |
| Packing speed |
1-3times/min |
| Heat sealing power(KW) |
1.5 |
| Head distance from the ground |
0~1070 mm |
| weight |
130kg |
| External dimensions(mm) |
800*700*1800 |
| vacuum pump power(kw) |
oil pump(0.9kw) |
| Maximum vacuum |
0.8mpa |
| Shell material |
Sus304 |
4. FAQ:
Q1: How to find a Packing machine suitable for my product?
To Longchuang distinguished customers and friends , in order to we have an accurate and efficient communication, please kindly consult us and provide following details as possible as you could .
1-Packing products:
2-Packing weight:
3-Dimension of the bag :
4-Bag type:
5-Packing capacity:
6-Products' feature:
If you have video or picture is very warm weclome.
For there are over 100 kinds of packing machine,different on bag sizes.
In order to recommend you the most suitable and best solution ,we need know these information.
Of course , if you are new and just start this business and don't have bag size , pls send us a sample picture or draft drawing)
, we can help you to find similar weight bag for your reference with our rich professional experience.
Q2: Can you send engineer service oversea?
Yes, and you need to pay some fee.
According to save your cost, we will send you a video of the installation of the machine.
Q3. How can we make sure about the machine's quality after we paid?
Before delivery, we will send you the pictures and videos of the machines.
And also you can visit our factory and test the machine.
Q4. We would like to have our own rand , is that ok ?
Yes, we accept OEM/ODM with your brand or your design.
Q5. Payment Method ?
1. 30% deposit, 70% before shipping.
2. We accept T/T, L/C etc.
Q6: Warranty
2 years for main parts after you received machines (Except the quick-wear parts)
Q7: About shipment:
You could designated freight logistics , we could also help for shipment by professionally .
5. Why Choose us ?
6. Machine picture:
7. Date printer ( Optional )
Main feature:
1. Adopt high-quality solid ink wheel, lower print costs Unique sliding print head, print more clearly
2. Ink wheel extraction device is simple and convenient, easy to replace the ink wheel
Application:
Applicable to all kinds of vertical intermittent, vertical continuous packaging machine matching code,Such as particle packaging machine, vertical molding filling sealing packaging machine, paper towel packaging machines. Widely used in food, medicine, cosmetic and other industries.
Technical Specifications:
Power source:motor
Power voltage:220V/50HZ
Power:220W
Printing speed:0-150 times/min
font size:2*3.4*7.2mm
print lines:1-3 lines
Consumable:Ink roll
Overall size:400*240*240mm
Weight:7kg
7. Bag samples:
8. Customer reputation:
